Doehler & Haass FCC
Accessory Decoder
The sensor module must be added to the Accessory Decoder table.
Bus & Address
Base decoder address on the SX bus.
Sub Address
The address on which the state byte is located.
This depends on how the module is configured.
Protocol Version
| Nr | Mode | Remark |
|---|---|---|
| 0 | Occupancy only | Classic occupancy detection. |
| 1 | Compatibility mode | SX1 address detection. |
| 2 | Full featured mode | SX1, SX2 and DCC address detection. |
Programming
- Select the wanted decoder from the dropdown list.
- Enable accessory programming.
- Optionally select the dh-rm.xml decoder definition file located in the decspecs folder.
- Read/Write the selected CV.
Note: Read the manual on how to set the sensor module in programming mode.
Server Trace
20190722.160932.642 r9999I sxReader OMttmFcc 1353 sensor mod=RM-10 addr=0:10 subaddr=14 ver=2 port=2 info=0x61 bidi1=0xE8 bidi2=0x92 20190722.160932.643 r9999I sxReader OMttmFcc 1263 DCC long 2408
